AHL-6300B

Transmission frequency

120GHZ~140GHZ

Material type

Particles, powders, and other bulk solids

measuring range

20M、50M、70M、120M

Communication methods

4-20mA/RS485/Ethernet/Fiber optic/4G/5G/Bluetooth

Protection level

IP67/IP68

ambient temperature

-40℃~80℃

working temperature

Conventional -40 ℃~80 ℃, can be equipped with cooling accessories

source

24VDC/220VAC

power

15W

Equipment weight

≤10KG

Number of point clouds

Greater than 600 points but less than 1000 points

Scanning cycle

30s-1min

Beam angle

1.5°

Horizontal rotation angle range

×

Horizontal step angle

×

Pitch measurement angle

0-90°（settable）

Pitch step angle

1°(adjustable)

accuracy

Level measurement accuracy：±2mm

working pressure

Volume accuracy：≤2%

Installation method

0…1bar,customizable

Communication methods

≥DN250 flange
